G6E-134P-ST-US-DC12 by omron electronics
Image is representational - see manufacturer specifications
Omron Electronics Authorized Distributor

G6E-134P-ST-US-DC12

Signal Relay 12VDC 3A SPDT(16x10x8)mm THT ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
End of Life: Final orders must be placed by 02/26/2027
Certificate of Compliance

DESCRIPTION

The G6E-134P-ST-US-DC12 is a Subminiature Low Signal Relay with DC coil. This G6E-series signal relay has SPDT Ag alloy bifurcated crossbar contact. Unique moving loop armature reduces relay size, magnetic interference and contact bounce time. Minimal loss of latching capability due to highly efficient magnetic circuit; also, highly resistant to shock and vibration. Sealed construction allows automatic solder and cleaning; assures high reliability even in adverse environments. Single side stable function Sealed construction Bifurcated crossbar contact assures high reliability 98mW Coil power consumption with high sensitivity Surge withstand voltage meets FCC part 68 rule and Bellcore 2.5kV -40 to 70°C Operating temperature range

Search Keywords: G6E134PSTUSDC12

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Omron Electronics
Part No:
G6E-134P-ST-US-DC12
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536490050
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Relay Construction:
Non-Latching12534
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
SPDT12514
Mounting:
Through Hole12526
Termination Style:
PC Pin12536
Operating Temperature:
-40 to 70 °C
Coil Resistance:
720 Ohm
End of Life:
Final orders must be placed by 02/26/2027

FREQUENTLY ASKED QUESTIONS

Is G6E-134P-ST-US-DC12 discontinued?

Yes, G6E-134P-ST-US-DC12 from Omron Electronics is discontinued (end-of-life February 2027). Master Electronics is an authorized distributor and may have remaining stock or a recommended replacement for it.

What replaces G6E-134P-ST-US-DC12?

The recommended replacement for G6E-134P-ST-US-DC12 is G6S-2-DC12 from Omron Electronics, available from Master Electronics.

Is G6E-134P-ST-US-DC12 RoHS compliant?

Yes, G6E-134P-ST-US-DC12 is RoHS compliant.

What is the lead time for G6E-134P-ST-US-DC12?

The standard lead time for G6E-134P-ST-US-DC12 is approximately 50 weeks. In-stock quantities ship from Master Electronics.

  End of Life: Final orders must be placed by 02/26/2027

IN STOCK: 0

On Order: 2,170   can ship 6/16/27

Minimum Order Quantity: 5

Factory Lead-Time 50 Weeks

Price (USD)

Qty
Unit Price
5
$7.12
25
$6.31
100
$5.92
250
$5.59
500
$5.44
1,000
$5.24
2,500
$5.23
5,000 +
$5.22
