G6A-274P-ST-US-DC12 by omron electronics
Image is representational - see mfr. specs

G6A-274P-ST-US-DC12

Omron Electronics

Signal Relay 12VDC 2A DPDT(20.2x10.1x8.4)mm THT ...

Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The G6A-274P-ST-US-DC12 is a Non-latching Low Signal Relay with DC coil. This G6A-series signal relay DPDT Ag (Au clad) bifurcated crossbar contacts. Stand-off 0.64mm classification and PCB terminals. Resistant to electromagnetic interference, enables high-density mounting. Impulse withstand voltage of 1500V meets FCC requirements. Gold-clad twin-contacts provide short contact bounce in addition to its high contact reliability. Single side stable function Fully sealed construction -40 to 70°C Operating temperature range UL/CSA Standards approved Applications Communications & Networking, Security, Medical, Test & Measurement

Search Keywords: G6A274PSTUSDC12

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Omron Electronics
Part No:
G6A-274P-ST-US-DC12
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410020
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
DPDT
Maximum Current Rating:
2 A
Mounting:
Through Hole
Operating Temperature:
-40 to 70 °C
Dimension:
20.2 x 10.1 x 8.4 mm
Termination Style:
PC Pin
Coil Current:
16.7 mA
Contact Form:
2 Form C

IN STOCK: 1,579

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 4 Weeks

Qty
Unit Price
5
$5.55
50
$4.51
100
$4.31
250
$4.18
500
$3.95
1,000
$3.85
2,500
$3.75
5,000 +
$3.70
