G5V-2-H-DC24 by omron electronics
Image is representational - see mfr. specs

G5V-2-H-DC24

Omron Electronics

Signal Relay 24VDC 2A DPDT( (20.5mm 10.1mm 12mm)) THT ...

Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The OMRON ELECTRONICS G5V-2-H-DC24 is a high-quality signal relay designed with a 24VDC coil voltage and a switching capability of up to 2A. Featuring a double pole double throw (DPDT) configuration, this relay is ideal for applications that require reliable and efficient switching control. With its compact size of 20.5mm x 10.1mm x 12mm, it can easily fit into various circuit boards and panels. This Through-Hole Technology (THT) relay is built with OMRON's renowned craftsmanship, ensuring long-lasting performance and durability.

Search Keywords: G5V2HDC24

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Omron Electronics
Part No:
G5V-2-H-DC24
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536490050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Relay Construction:
Non-Latching12534
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
DPDT12514
Maximum Current Rating:
2 A
Mounting:
Through Hole12526
Operating Temperature:
-25 to 70 °C
Dimension:
20.5 x 10.1 x 11.5 mm
Termination Style:
PC Pin12536
Coil Current:
15 mA
Contact Form:
2 Form C12515

IN STOCK: 734

Can Ship immediately

On Order: 1,000   can ship 5/27/26

Minimum Order Quantity: 10

Factory Lead-Time 7 Weeks

Qty
Unit Price
10
$2.767
100
$2.108
250
$1.974
500
$1.906
1,000
$1.840
2,500
$1.836
5,000
$1.722
7,500 +
$1.717
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides

Product Changes
