B3W-1000 by omron electronics
Image is representational - see manufacturer specifications
Omron Electronics Authorized Distributor

B3W-1000

Switch Tactile N.O. SPST Flat Plunger PC Pins 0.05A 24VDC 1000000Cycles 1.57N Thru-Hole Bag ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The OMRON ELECTRONICS part B3W-1000 is a high-quality tactile switch designed for reliable and precise operation in various electronic applications. This switch features a normally open (N.O.) configuration with a single-pole, single-throw (SPST) contact arrangement and a flat plunger design. It is equipped with PC pins for easy and secure connection to the printed circuit board.With a current rating of 0.05A and a voltage rating of 24VDC, this switch ensures efficient and safe performance. It has an impressive durability with a guaranteed lifespan of 1,000,000 cycles, making it ideal for demanding industrial and commercial environments. The switch is designed for through-hole mounting, allowing for easy installation and stability.The OMRON B3W-1000 features a actuation force of 1.57N, providing a tactile feedback that ensures accurate and responsive operation. It is packaged in a convenient bag format, allowing for easy handling and storage. Overall, this switch offers exceptional reliability, longevity, and performance, making it an excellent choice for various electronic applications.

Search Keywords: B3W1000

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Omron Electronics
Part No:
B3W-1000
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509065
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1500
Dimension:
6.6 x 7.7 x 4.3 mm
Mounting:
PCB Through Hole
Pole Throw Configuration:
SPST
Switch Configuration:
N.O.
Actuator Style:
Flat Plunger
Operating Force:
1.57 N
Contact Rating @ Voltage:
0.05@24VDC A
Illumination Type:
N/R
Body Orientation:
Straight
Termination Style:
PC Pins
Seal:
Rubber
Seal Location:
Construction

FREQUENTLY ASKED QUESTIONS

Is B3W-1000 RoHS compliant?

Yes, B3W-1000 is RoHS compliant.

What is the lead time for B3W-1000?

The standard lead time for B3W-1000 is approximately 26 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 27,804

Can Ship immediately

Minimum Order Quantity: 50

Factory Lead-Time 26 Weeks

Price (USD)

Qty
Unit Price
50
$0.5273
500
$0.4289
1,500
$0.4205
3,000
$0.4194
6,000
$0.4139
10,500
$0.4080
15,000
$0.4070
25,500 +
$0.4060
Supplier's Standard Package
