LY2NAC24 by omron automation
Image is representational - see mfr. specs

LY2NAC24

Omron Automation

The LY2NAC24 is a 2-pole, general-purpose plug-in relay with a built-in operation indicator and a 24 VAC coil. ...

Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The LY2NAC24 is a compact, power-switching general-purpose relay designed for various control applications. This 2-pole relay features a 24 VAC coil with a power consumption of approximately 1.0 to 1.2 VA and includes a built-in operation indicator. It is equipped with silver alloy contacts rated for a resistive load of 10 A at 110 VAC and an inductive load of 7.5 A at 110 VAC. The relay features an arc barrier for arc interruption and has a high dielectric strength of 2,000 VAC between the coil and contacts. Its compact design and compliance with UL and CSA safety standards make it suitable for power-switching in industrial controls, automation systems, and commercial equipment.

Search Keywords: LY2NAC24

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Omron Automation
Part No:
LY2NAC24
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410020
COO:
ID
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Relay Construction:
Non-Latching
AC Coil Voltage:
24 V
DC Coil Voltage:
N/A
Contact Arrangement:
DPDT
Maximum Current Rating:
10 A
Mounting:
Socket
Termination Style:
Quick Connect
Push to Test Button:
No
Led Indicator:
Yes
Operating Temperature:
-25 to 55 °C
Coil Resistance:
180 Ohm

IN STOCK: 55

Can Ship immediately

Manufacturer Stock: 1,093   can ship 5/4/26

Minimum Order Quantity: 5

Factory Lead-Time 36 Weeks can ship 12/30/26

Qty
Unit Price
5
$12.63
25
$12.37
50
$12.31
100
$12.25
250
$12.19
500
$12.13
1,000 +
$12.07
