172-E15-103R001 by norcomp
Image is representational - see manufacturer specifications
Norcomp Authorized Distributor

172-E15-103R001

Male D-Sub 15 Position Straight Solder Cup ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The 172-E15-103R001 is a 15-position male D-sub connector from the 172-E economy series, designed for wire termination via solder cups. It features machined, gold-plated brass contacts that accommodate wire gauges from 26 to 20 AWG. The connector is constructed with a durable nickel-plated steel shell and a glass-filled nylon thermoplastic insulator rated UL94 V-0. Key electrical specifications include a 5A current rating, 250VAC working voltage, and a maximum contact resistance of 15 mOhms. This component is designed to operate in a wide temperature range from -55°C to +125°C, making it suitable for various industrial and electronic applications.

Search Keywords: 172E15103R001

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Norcomp
Part No:
172-E15-103R001
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
TW
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Cable Mount
Gender:
M
Termination Method:
Solder Cup
Shell Size:
A
Number of Contacts:
15
Contact Plating:
Gold
Operating Temperature:
-50 to 100 °C

FREQUENTLY ASKED QUESTIONS

Is 172-E15-103R001 RoHS compliant?

Yes, 172-E15-103R001 is RoHS compliant.

What is the lead time for 172-E15-103R001?

The standard lead time for 172-E15-103R001 is approximately 17 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 0

On Order: 2,000   can ship 12/24/26

Minimum Order Quantity: 50

Multiple: 50

Factory Lead-Time 17 Weeks

Price (USD)

Qty
Unit Price
50
$3.48
100
$3.29
250
$3.05
500
$2.91
1,000
$2.72
2,500
$2.55
5,000
$2.54
7,500 +
$2.53
Supplier's Standard Package
