NHD-0420E2Z-NSW-BBW by newhaven display
Image is representational - see mfr. specs

NHD-0420E2Z-NSW-BBW

Newhaven Display

LCD Character Display - 4 x 20 Character - STN- Blue - White Backlight - 146.0 x 62.5 mm ...

Datasheet
RoHS Compliant
BULK Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The NHD-0420E2Z-NSW-BBW is a 4 x 20 Character LCD Character Display. It features a STN- Blue Transmissive Display with a White Backlight. Character size is 9.22 x 4.84 mm. It uses an 8-Bit Parallel Interface. Voltage requirement is 5V. Controller required is the KS0066U

Search Keywords: NHD0420E2ZNSWBBW

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Newhaven Display
Part No:
NHD-0420E2Z-NSW-BBW
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8524919000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
BULK
Display Format:
4 x 20 Characters
Display Type:
STN- BLUE
Display Mode:
Transmissive
Text Color:
White
Background Color:
Blue
Backlight:
LED - White
Active Area:
118.84 x 38.47 mm
Character Size:
9.22 x 4.84 mm
Dimension:
146 x 62.5 mm
Interface:
8-Bit Parallel
Supply Voltage:
5 V
Operating Temperature:
-20 to +70 °C

IN STOCK: 832

Ships today, if you order in

Factory Lead-Time 16 Weeks

Qty
Unit Price
1
$29.88
5
$27.10
10
$25.13
25
$24.88
50
$23.88
100
$23.82
250 +
$23.76
Log in for special pricing Click for Quote Price Match Request
