NHD-0420D3Z-NSW-BBW-V3 by newhaven display

NHD-0420D3Z-NSW-BBW-V3

Newhaven Display

Serial LCD - 4 x 20 Character - STN-Blue - White Backlight - 98.0 x 60.0 mm ...

Datasheet
RoHS Compliant
Bulk Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The NHD-0420D3Z-NSW-BBW-V3 is a 4 x 20 Character Serial LCD. It features a STN-Blue Transmissive Display with a White Backlight. Character size is 4.75 x 2.95 mm. It uses an I2C, RS232, SPI Interface. Voltage requirement is 5V. Controller required is the PIC 16F690

Search Keywords: NHD0420D3ZNSWBBWV3

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Newhaven Display
Part No:
NHD-0420D3Z-NSW-BBW-V3
RoHS:
Yes
HTS:
8524919000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Bulk
Display Format:
4 x 20 Characters
Display Type:
STN-BLUE
Display Mode:
Transmissive
Text Color:
White
Background Color:
Blue
Backlight:
LED - White
Active Area:
70.4 x 20.8 mm
Character Size:
4.75 x 2.95 mm
Dimension:
98 x 60 x 13.5 mm
Interface:
I2C, RS232, SPI
Supply Voltage:
5 V
Operating Temperature:
-20 to +70 °C
  Possible Replacement options available.  See Alternatives

IN STOCK: 338

Can Ship immediately

Factory Lead-Time 15 Weeks

Qty
Unit Price
1
$36.01
5
$33.71
10
$32.71
25
$31.41
50
$30.41
100
$29.42
250 +
$28.11
Log in for special pricing
Please Note: Tariffs may apply for U.S. shipments
