NC3FAH by neutrik
Image is representational - see manufacturer specifications
NEUTRIK Authorized Distributor

NC3FAH

A Series - 3 pole female XLR receptacle - grounding: without ground/shell contact - horizontal PCB mount The `State of the Art` receptacle. Round plastic body XLR PCB mount panel connector. These have the smallest size and highest packing density (23mm ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The NC3FAH is 3 pole female XLR receptacle, grounding: without ground/shell contact, horizontal PCB mount The NC3FAH has rated voltage of < 50 V and rated current per contact of 6 A and dielectric strength of 1,5 kVdc . The `State of the Art` receptacle. Round plastic body XLR PCB mount panel connector. These have the smallest size and highest packing density (23mm between centres). New designed tulip type contacts with hard gold plating and polished contact areas. UL recognized component.

Product Highlights:

  • Smallest XLR receptacles, highest packing density
  • Plastic housing, steel latch lock
  • Tulip type female contact
  • Polished contact areas and hard gold plating
  • Housing flammability UL94V-0

Search Keywords: NC3FAH

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
NEUTRIK
Part No:
NC3FAH
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
LI
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Type:
XLR Connector
Gender:
F
Body Orientation:
Right Angle
Mounting:
Through Hole
Housing Material:
Polyamide
Number of Contacts:
3
Contact Plating:
AuCo Over NiP15
Termination Method:
Solder
Operating Temperature:
-30 to 80 °C

FREQUENTLY ASKED QUESTIONS

Is NC3FAH RoHS compliant?

Yes, NC3FAH is RoHS compliant.

What is the lead time for NC3FAH?

The standard lead time for NC3FAH is approximately 3 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 946

Can Ship immediately

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 3 Weeks

Price (USD)

Qty
Unit Price
100
$1.97
300
$1.92
500
$1.84
1,000
$1.83
2,500
$1.82
5,000
$1.81
7,500
$1.80
10,000 +
$1.79
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request
