TC1262-3.3VDBTR by microchip technology
Image is representational - see manufacturer specifications
Microchip Technology Authorized Distributor

TC1262-3.3VDBTR

Fixed LDO Voltage Regulator - 2.7V to 6V - 350mV Dropout - 3.3Vout - 500mAout - SOT-223 - 4-Pin(3+Tab). ...

View Datasheet Ask the Datasheet
RoHS Compliant
REEL Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The TC1262-3.3VDBTR is a fixed output high accuracy CMOS Low Dropout Regulator (LDO) for battery-operated systems. The TC1262 is CMOS construction eliminates wasted ground current, significantly extending battery life. Total supply current is typically 80µA at full load (20 to 60 times lower than in bipolar regulators). TC1262 key features include ultra low noise, very low dropout voltage (typically 350mV at full load) and fast response to step changes in load. The TC1262 incorporates both over-temperature and over-current protection. The TC1262 is stable with an output capacitor of only 1µF and has a maximum output current of 500mA.

Search Keywords: TC126233VDBTR

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Microchip Technology
Part No:
TC1262-3.3VDBTR
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8542390090
COO:
TW
ECCN:
EAR99
Reel Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
4000
Package Type:
REEL
Function:
LDO
Line Regulation:
0.003(Typ) %
Dimension:
6.5 x 3.5 x 1.6 mm
Accuracy:
±0.5 %
Load Regulation:
0.002(Typ) %
Family:
TC1262
Maximum Dropout Voltage @ Current:
0.03@100uA,0.13@100mA,0.39@300mA,0.65@500mA V
Junction to Case:
N/A
Junction to Ambient:
59 °C/W

FREQUENTLY ASKED QUESTIONS

Is TC1262-3.3VDBTR RoHS compliant?

Yes, TC1262-3.3VDBTR is RoHS compliant.

What is the lead time for TC1262-3.3VDBTR?

The standard lead time for TC1262-3.3VDBTR is approximately 9 days. In-stock quantities ship from Master Electronics.

IN STOCK: 785

Can Ship immediately

Manufacturer Stock: 8,000   can ship 8/24/26

On Order: 4,000   can ship 10/12/26

Minimum Order Quantity: 500

Factory Lead-Time 9 Weeks can ship 10/12/26

Price (USD)

Qty
Unit Price
500
$0.681
1,000
$0.676
4,000
$0.673
8,000
$0.672
12,000
$0.670
16,000
$0.668
28,000 +
$0.666
Reel Package
