PIC18F66K80-E/PT by microchip technology

PIC18F66K80-E/PT

Microchip Technology

PIC 18 microcontroller - MCU 8 bit - RISC architecture - 75 Instructions - 1.8 V to 5.5 V - Pins: 64 - Package type: TQFP 64 – Speed 64 MHz - Flash 64 KB – SRAM 3648 bytes – EEPROM 1024 bytes - I/O: 54 – A/D: 10 bit with 11 channels – 05 Timers – MSSP – 0 ...

Datasheet
RoHS Compliant
TRAY Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
This product may require extra documentation. Shipping may be delayed 1-2 days.

DESCRIPTION

The MICROCHIP TECH PIC18F66K80-E/PT is part of PIC18 family with a 8-Bit RISC microcontroller. It can sustain standard temperature ranges from -40°C to + 125 C, has 64 pin in TQFP-64 package and 64 MHz clock speed. This device has a Flash memory of 64 KB, a SRAM of 3648 bytes, EEPROM of 1024 bytes, five timers module and 11 channels of 10 bits ADC. This MCU includes MSSP & EUSART communication modules (I2C & SPI modules) with 54 I/O pins. It can be used to achieve various tasks.

Search Keywords: PIC18F66K80EPT

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Microchip Technology
Part No:
PIC18F66K80-E/PT
RoHS:
Yes
HTS:
8542310015
COO:
TH
ECCN:
3A991.a.2
Supplier Standard Pack  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
160
Package Type:
TRAY
Number of Programmable I/Os:
54
Program Memory Size:
64 KB
RAM Size:
3648 B
ADC Resolution:
12 bit
Program Memory Type:
Flash
Operating Temperature:
-40 to 125 °C

IN STOCK: 0

On Order: 285   can ship 1/19/26

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 40

Factory Lead-Time 8 Weeks

Qty
Unit Price
5
$6.05
10
$5.84
25
$5.33
40
$5.31
80
$5.02
120
$4.75
160 +
$4.73
