PIC16F946-I/PT

PIC 16 microcontroller - MCU 8 bit - RISC architecture - 35 Instructions - Interrupts 10 - 2 V to 5.5 V - Pins: 64 - Package type: TQFP 64 – Speed 20MHz - Flash 8 K words – SRAM 336 Bytes – EEPROM 256 Bytes - I/O: 53 – A/D: 10 bit with 08 channels – 02 x ...

Datasheet

RoHS Compliant

TRAY Packaging

DESCRIPTION

The MICROCHIP TECH PIC16F917-I/PT is part of PIC16F mid-range family with a 8-Bit RISC microcontroller. It can sustain standard temperature ranges from -40°C to +85°C, has 44 pin in TQFP-64 package and 20 MHz clock speed. This device has a Flash memory of 8 K words, a SRAM of 336 bytes, EEPROM of 256 bytes, three timers and two CCP module and 08 channels of 10 bits ADC. This MCU includes SSP & AUSART communication modules (I2C & SPI modules) with 53 I/O pins. It can be used to achieve various tasks.

Product Highlights:

Potential Applications:

Search Keywords: PIC16F946IPT

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Microchip Technology

Part No:

PIC16F946-I/PT

RoHS:

Yes

HTS:

8542310015

COO:

ECCN:

EAR99

Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
