MIC2026-2YM-TR by microchip technology
Image is representational - see manufacturer specifications
Microchip Technology Authorized Distributor

MIC2026-2YM-TR

USB Power Distribution Switch - Current Limit - Active Low - 2 Outputs - 0.09 ohm On - 5.5 V - 0.9 A - SOIC - 8-Pin. ...

View Datasheet Ask the Datasheet
RoHS Compliant
REEL Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The MIC2026 and MIC2076 are high-side MOSFET switches optimized for general-purpose power distribution requiring circuit protection. The MIC2026/76 are internally current limited and have thermal shutdown that protects the device and load. The MIC2076 offers "smart" thermal shutdown that reduces current consumption in fault modes. When a thermal shutdown fault occurs, the output is latched off until the faulty load is removed. Removing the load or toggling the enable input will reset the device output. Both devices employ soft-start circuitry that minimizes inrush current in applications where highly capacitive loads are employed. A fault status output flag is asserted during overcurrent and thermal shutdown conditions. Transient faults are internally filtered. The MIC2026/76 are available in 8-pin DIP or 8-pin SOIC.

Search Keywords: MIC20262YMTR

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Microchip Technology
Part No:
MIC2026-2YM-TR
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8542390090
COO:
MY
ECCN:
EAR99
Reel Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
2500
Package Type:
REEL
Maximum Power Dissipation:
N/A
Dimension:
4.93 x 3.94 x 1.48 mm
Family:
MIC2026
Maximum Input Voltage:
5.5 V
Enable Logic:
Active Low
Current Limit:
1 A

FREQUENTLY ASKED QUESTIONS

Is MIC2026-2YM-TR RoHS compliant?

Yes, MIC2026-2YM-TR is RoHS compliant.

What is the lead time for MIC2026-2YM-TR?

The standard lead time for MIC2026-2YM-TR is approximately 26 days. In-stock quantities ship from Master Electronics.

  Different packaging options available.  See Alternatives

IN STOCK: 2,850

Can Ship immediately

Minimum Order Quantity: 500

Factory Lead-Time 26 Weeks

Price (USD)

Qty
Unit Price
500
$0.995
1,000
$0.993
2,500
$0.990
5,000
$0.988
7,500
$0.985
10,000
$0.983
15,000
$0.980
25,000 +
$0.978
Reel Package
Log in for special pricing Click for Quote Price Match Request
