MCP1525T-I/TT by microchip technology
Image is representational - see manufacturer specifications
Microchip Technology Authorized Distributor

MCP1525T-I/TT

Voltage Reference - Precision - Series - Fixed - 2.5V - 8mA - SOT-23-3 - 3-Pin. ...

View Datasheet Ask the Datasheet
RoHS Compliant
REEL Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The MCP1525T-I/TT is a low power, high precision voltage reference in 3 pin SOT-23 package. This voltage reference is normally used in 3V to 5V systems where wide variations in supply voltage exists and need to minimize power dissipation. The MCP1525 use combination of an advanced CMOS circuit design and EEPROM trimming to provide an initial tolerance of 1% and temperature stability of 50ppm/°C. This device offers clear advantage over traditional zener techniques in terms of stability across time and temperature.

Search Keywords: MCP1525TITT

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Microchip Technology
Part No:
MCP1525T-I/TT
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8542390090
COO:
TH
ECCN:
EAR99
Reel Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
3000
Package Type:
REEL
Maximum Temperature Coefficient:
50 ppm/°C
Mounting:
Surface Mount
Family:
MCP1525
Maximum Output Current:
8(Typ) mA
Initial Accuracy:
1 %
Maximum Input Voltage:
7 V
Load Regulation:
1.3 mV/ mA
Line Regulation:
350 uV/V
Dimension:
2.9 x 1.3 x 0.95 mm

FREQUENTLY ASKED QUESTIONS

Is MCP1525T-I/TT RoHS compliant?

Yes, MCP1525T-I/TT is RoHS compliant.

What is the lead time for MCP1525T-I/TT?

The standard lead time for MCP1525T-I/TT is approximately 4 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 34,450

Can Ship immediately

Manufacturer Stock: 294,600   can ship 10/12/26

Minimum Order Quantity: 500

Factory Lead-Time 4 Weeks can ship 10/26/26

Price (USD)

Qty
Unit Price
500
$0.878
1,000
$0.872
3,000
$0.742
6,000
$0.740
9,000
$0.738
12,000
$0.736
15,000
$0.734
27,000 +
$0.732
Reel Package
