HLG-320H-12A by mean well

HLG-320H-12A

Mean Well

AC/DC LED Power Supply – 12VDC - 264W-22A- Constant Current/Constant Voltage – Input from 90 to 305VAC – No dimming function. ...

Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The HLG-320H-12A is a 264W AC/DC LED driver featuring a dual mode constant voltage and constant current output. HLG-320H-12A operates from 90 to 305VAC. Voltage output is adjustable from 10.8 to 13.5 VDC and current output adjustable from 11 to 22 A with rated current of 22A. Thanks to the high efficiency up to 91%,with the fanless design, it is able to operate from -40℃ ~ +90℃ case temperature under free air convection. The design of metal housing and IP67/IP65 ingress protection level allows this series to fit both indoor and outdoor applications. HLG-320H-12A is equipped with various function options, such as built in potentiometer to adjust ouput current and voltage, so as to provide the optimal design flexibility for LED lighting system. The HLG-320H-12A has a typical lifetime of 62000 hours and a 7-year factory warranty.

Search Keywords: HLG320H12A

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Mean Well
Part No:
HLG-320H-12A
RoHS:
Yes
HTS:
8504409510
COO:
TW
ECCN:
EAR99
Supplier Standard Pack  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Input/Output Type:
AC/DC8097
Style:
Enclosed
Type:
Constant Current/Voltage
Output Type:
Adjustable
Dimming:
No
Maximum Output Power:
264 W
Output Voltage Range:
6.0 to 12.0 Vdc
Maximum Output Current:
22,000 mA (22.0 A)
Minimum AC Input Voltage:
90
Maximum AC Input Voltage:
305
Minimum DC Input Voltage:
127
Maximum DC Input Voltage:
431
Termination Style:
Wire Leads
Input Connector Type:
Stripped and Tinned
Output Connector Type:
Stripped and Tinned
Operating Temperature:
-40 to 90 °C
Safety Agency Approvals:
CB, CCC, CE, cRUus, PSE, RCM, TUV
IEC Class:
None
SELV:
Yes
LPS:
No
Warranty:
7 Years
Family:
HLG-320H

IN STOCK: 377

Ships today, if you order in

Factory Lead-Time 16 Weeks

Qty
Unit Price
1
$96.10
5
$91.60
10
$87.50
20 +
$85.00
Log in for special pricing
Please Note: Tariffs may apply for U.S. shipments
