HVPB107-CH by marathon special products
Image is representational - see mfr. specs

HVPB107-CH

Marathon Special Products

The HVPB107-CH is a power terminal block with a snap-on hinged cover, rated for 430 Amps and up to 1500V. ...

Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The HVPB107-CH is a power terminal block designed for high-current applications, which includes a snap-on hinged cover. It is rated for 430 Amps and has a maximum voltage rating of 1500V per UL 1059 Class E, with a Short Circuit Current Rating (SCCR) of 10,000A. The block utilizes M10 x 35 mm studs for both line and load side terminations, accommodating listed lugs up to 39 mm wide. Constructed with a UL94V0-rated thermoplastic insulator base, it operates reliably in temperatures from -40°C to 110°C, making it suitable for factory and field wiring in demanding industrial environments.

Search Keywords: HVPB107CH

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Marathon Special Products
Part No:
HVPB107-CH
Unit of Measure:
Per Each
RoHS:
Yes
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Type:
Power Terminal Block
Mounting:
Panel Mount
Gender:
N/A
Termination Method:
Screw
Pitch:
N/R
Number of Circuits:
1
Maximum Voltage Rating:
1500,1500 VDC|VAC
Maximum Current Rating:
430 A
Wire Size:
N/A
Operating Temperature:
N/A

IN STOCK: 37

Can Ship immediately

Factory Lead-Time 8 Weeks

Qty
Unit Price
1
$103.75
5
$79.53
10
$67.66
25
$65.53
50
$65.20
100
$64.87
250 +
$64.55
