SCH628R

The SCH628R is a panel-mount, continuous tone alarm designed for use in Class I Division II hazardous locations. ...

RoHS Compliant

DESCRIPTION

The SCH628R is a panel alarm from the Mallory Sonalert SCH series that produces a medium-level, continuous audible signal. It operates on a voltage range of 6 to 28 Vdc and draws a maximum current between 3 and 18 mA. This device emits a 2900 Hz tone with a sound pressure level of 68 to 80 dBa measured at 2 feet. The alarm is housed in a 1.69 x 0.81-inch enclosure with screw terminals for easy installation. Certified for hazardous locations (Class I, Div II) and rated to IP-66 and NEMA 3R/4X/12 standards, it is ideal for industrial process control and safety signaling applications in harsh environments.

Product Highlights:

Potential Applications:

Search Keywords: SCH628R

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Mallory Sonalert

Part No:

SCH628R

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8531809041

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
