PF-27N25WQ by mallory sonalert
Image is representational - see mfr. specs

PF-27N25WQ

Mallory Sonalert

The PF-27N25WQ is a panel-mount audio indicator that produces a fast pulsed tone at a frequency of 2500 Hz. ...

Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PF-27N25WQ is an electronic audio indicator designed to provide a clear audible signal. It operates over a wide voltage range of 3 to 28 VDC, with a rated voltage of 12 VDC, and produces a minimum sound pressure level of 90 dB at 30 cm. This device features an oscillation frequency of 2500 ±500 Hz and a fast pulse rate of 3.0 Hz, while consuming a maximum of 15 mA at its rated voltage. Housed in black ABS plastic and equipped with 28 AWG lead wires, it is built to function reliably in temperatures from -20°C to +70°C. The PF-27N25WQ is suitable for various applications requiring a distinct audible alert, such as in control panels, alarm systems, and electronic equipment.

Search Keywords: PF27N25WQ

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Mallory Sonalert
Part No:
PF-27N25WQ
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8531809041
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Minimum Operating Supply Voltage:
3 VDC
Maximum Operating Supply Voltage:
28 VDC
Termination Method:
Wire Lead
Minimum Sound Pressure:
90 dBA
Mounting:
Flange Mount

IN STOCK: 161

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 24 Weeks

Qty
Unit Price
5
$21.78
25
$12.07
50
$10.73
100
$10.50
250
$10.17
500
$10.12
1,000 +
$10.07
