83100000005 by littelfuse
Image is representational - see mfr. specs

83100000005

Littelfuse

Fuse Holder 1 Fuse 5mm x 20mm Enclosed Bayonet Style 250VAC 250VDC 16A Bulk ...

Datasheet
RoHS Compliant
BULK Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 83100000005 is a miniature fuseholder (Holder No. 831) designed for PC-mount applications with 5x20mm fuses in a vertical 4-pin configuration. It features a shocksafe design rated at 250V with a rated current of 6.3A (VDE/SEMKO) or 16A (UL/CSA) and a rated power of 2.5W, utilizing four solder pins (0.5mm × 1.1mm) spaced at 5.08mm pitch for common connection on printed circuit boards. The holder is constructed from black thermoplastic polyamide PA 6.6 (UL94 V-0) with copper alloy metal parts and tinned solderable terminals, offering contact resistance of =5mO and dielectric strength exceeding 1.5 kV. It operates across -25°C to +70°C, withstands vibration testing at 10–2000 Hz with 0.75mm amplitude (10–60 Hz) and 10g acceleration (60–2000 Hz), and maintains insulation resistance greater than 10³ MO at 500 VDC. This fuseholder is ideal for circuit protection in consumer electronics, industrial control systems, and appliances requiring compact, reliable fuse mounting with international approvals (VDE, SEMKO, UL, CSA).

Search Keywords: 83100000005

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Littelfuse
Part No:
83100000005
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CH
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
BULK

IN STOCK: 0

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
100
$1.69
200
$1.60
400
$1.52
800 +
$1.45
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides
