V80212MA08Q by littelfuse/c-k
Image is representational - see mfr. specs

V80212MA08Q

Littelfuse/C&K

The V80212MA08Q is a DPDT power slide switch featuring a right-angle, PC thru-hole mounting style and horizontal actuation. ...

Datasheet
RoHS Compliant
TRAY Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The V80212MA08Q is a V Series DPDT power and line voltage select slide switch designed for right-angle, PC thru-hole mounting. It features a side-actuated, screwdriver slot actuator for horizontal operation and utilizes '08' style PC thru-hole terminations. This RoHS-compliant switch has silver-plated copper contacts and is rated for up to 10A at 125V AC, with an electrical life of 10,000 cycles at full load. It operates reliably over a temperature range of -30°C to +85°C and offers a low initial contact resistance of less than 10 mΩ. With its robust specifications, this switch is well-suited for power selection tasks in appliances and other electronic devices.

Search Keywords: V80212MA08Q

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Littelfuse/C&K
Part No:
V80212MA08Q
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
853650
COO:
VN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
36
Package Type:
TRAY
Mounting:
PCB Through Hole
Body Orientation:
Right Angle
Actuator Style:
Screwdriver
Pole Throw Configuration:
DPDT
Switch Configuration:
On On
Contact Rating @ Voltage:
10@125VAC A
Contact Plating:
Silver
Operating Temperature:
-30 to 85 °C
Termination Style:
PC Pins
Dimension:
26.19mm x 26.58mm x 16.51mm

IN STOCK: 20,375

Ships today, if you order in

Minimum Order Quantity: 36

Multiple: 36

Factory Lead-Time 6 Weeks

Qty
Unit Price
36
$5.51
72
$5.42
108
$5.22
252
$5.00
504
$4.84
1,008
$4.76
2,520
$4.74
5,004 +
$4.71
Suppliers Standard Package
