PN11SHNA03QE by littelfuse/c-k
Image is representational - see mfr. specs

PN11SHNA03QE

Littelfuse/C&K

The PN11SHNA03QE is a non-shorting, SPDT momentary pushbutton switch with a 2.8 mm square tip actuator and an actuation force of 250 g. ...

Datasheet
RoHS Compliant
TRAY Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PN11SHNA03QE is a non-shorting, SPDT momentary pushbutton switch from the PN Series. It is designed with a 2.8 mm square tip actuator and has a typical actuation force of 250 grams. This component is rated for 0.2 A at 30 V DC and offers a reliable electrical and mechanical life of 10,000 cycles. The switch features an initial contact resistance of 30 mΩ maximum, an insulation resistance of 100 MΩ minimum, and an epoxy terminal seal for enhanced durability. It is typically used in computers, peripherals, instrumentation, measurement equipment, and other non-power on-off switch applications.

Search Keywords: PN11SHNA03QE

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Littelfuse/C&K
Part No:
PN11SHNA03QE
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
853650
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
910
Package Type:
TRAY
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Bushing Type:
N/R
Switch Configuration:
N.O./N.C.
Contact Rating @ Voltage:
0.2A@30 VDC
Actuator Style:
Square Plunger
Illumination:
N/R
Terminal Type:
PC Pins
Body Orientation:
Right Angle
Dimension:
5 x 22 x 8.3 mm

IN STOCK: 0

On Order: 1,717   can ship 7/6/26

Minimum Order Quantity: 25

Factory Lead-Time 14 Weeks

Qty
Unit Price
25
$1.38
250
$1.19
910
$1.08
1,820
$1.04
2,730
$1.03
5,460 +
$1.02
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
