EP11SD1CBE

Sealed Tiny Pushbutton Switches-SPST- Sealed - IP57-Off-Mom-60,000 cycles-20V-.4A ...

View Datasheet Ask the Datasheet
RoHS Compliant
OTHER Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The EP11SD1CBE with dimensions 8.13 x 5.08 x 18.85 mm has Through Hole mounting with SPST Pole throw configuration ,Off-Mom switching configuration and Round Plunger actuator. The EP11SD1CBE has contact rating of .4A@20VDC. This Sealed - IP57 switch has Surface Mount termination style with Right Angle body orientation. The EP series of sealed tiny pushbutton switches from C&K are selected to power applications in the telecommunications and networking industry. The EP’s snap-fitting actuator accepts standard caps, and is sealed to protect against solder and cleaning processes – helping ensure it can withstand any harsh environment. Available in thru-hole and surface mount models, C&K’s EP switches are also RoHS compliant.

Search Keywords: EP11SD1CBE

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Littelfuse / C&K
Part No:
EP11SD1CBE
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
853650
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
200
Package Type:
OTHER
Mounting:
Through Hole
Pole Throw Configuration:
SPST
Bushing Type:
Unthreaded
Switch Configuration:
OFF Mom
Contact Rating @ Voltage:
0.4A@20VAC 20 VDC
Actuator Style:
Round Plunger
Illumination:
N/R
Terminal Type:
PC Pins
Body Orientation:
Straight
Dimension:
8.13 x 5.08 x 18.85 mm

FREQUENTLY ASKED QUESTIONS

Is EP11SD1CBE RoHS compliant?

Yes, EP11SD1CBE is RoHS compliant.

What is the lead time for EP11SD1CBE?

The standard lead time for EP11SD1CBE is approximately 15 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 2,635

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 15 Weeks
