BD02 by littelfuse / c-k
Image is representational - see manufacturer specifications
Littelfuse / C&K Authorized Distributor

BD02

Standard Profile DIP switch-100 mA max. @ 50 V DC.-Thru-hole-Unsealed-2N-2 positions. ...

View Datasheet Ask the Datasheet
RoHS Compliant
TUBE Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The BD02 with dimensions 7.11mm x 9.65mm x 7.54mm has Thru-hole mounting with SPST Pole throw configuration ,SPST switching configuration and Slide Standard actuator. The BD02 has operating force of 2 N and contact rating of 100mA@50V. This unsealed switch has thru-hole termination style with Straight body orientation.With an extended actuator for easy actuation and an open bottom construction that allows for solder washing without the need for a tape seal, BD series standard profile DIP switches from C&K are used by designers for function controlling, logic switching in computers and peripherals and industrial control address switches and automotive applications.

Search Keywords: BD02

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Littelfuse / C&K
Part No:
BD02
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509050
COO:
VN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
74
Package Type:
TUBE
Body Orientation:
Straight
Actuator Style:
Extended Slide
Actuator Length:
0.9 mm
Number of Positions:
2
Pole Throw Configuration:
SPST
Mounting:
Through Hole
Terminal Type:
PC Pins
Contact Rating @ Voltage:
0.1@5VDC A
Terminal Pitch:
2.54 mm

FREQUENTLY ASKED QUESTIONS

What replaces BD02?

The recommended replacement for BD02 is QFPF02RD from Littelfuse / C&K, available from Master Electronics.

Is BD02 RoHS compliant?

Yes, BD02 is RoHS compliant.

What is the lead time for BD02?

The standard lead time for BD02 is approximately 15 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 23,766

Can Ship immediately

Minimum Order Quantity: 74

Multiple: 74

Factory Lead-Time 15 Weeks
