8531J81ZQE22 by littelfuse / c-k
Image is representational - see manufacturer specifications
Littelfuse / C&K Authorized Distributor

8531J81ZQE22

Subminiature Pushbutton Switches ...

View Datasheet Ask the Datasheet
RoHS Compliant
TRAY Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

8531J81ZQE22 is a subminiature pushbutton switch from C&K Components' 8500 Series, designed for detection, telecommunications, and computer peripheral applications. This single-pole single-throw (SPST) normally open momentary switch features a total travel of 0.095" (2.41 mm) typical with 0.042" (1.07 mm) overtravel, and an actuation force of 7.7 oz (220g) typical. The switch is equipped with a J81 snap-in frame actuator for panel mounting (panel thickness 0.047" to 0.125"), solder lug (Z) terminations, and Q contact material rated at 1 AMP @ 120 V AC or 28 V DC. It offers reliable contact design with contact resistance below 30 mO typical, insulation resistance of 10?O minimum, and an electrical life of 250,000 actuations at full load. The switch operates over a temperature range of -30°C to 65°C and is RoHS compliant.

Search Keywords: 8531J81ZQE22

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Littelfuse / C&K
Part No:
8531J81ZQE22
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
853650
COO:
VN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
80
Package Type:
TRAY
Mounting:
Panel Mount
Pole Throw Configuration:
SPST
Bushing Type:
Threaded
Switch Configuration:
OFF Mom
Contact Rating @ Voltage:
1A@120VAC 28 VDC
Actuator Style:
Square Button
Illumination:
N/R
Terminal Type:
Solder
Body Orientation:
Straight
Dimension:
9.53 x 9.53 x 27.62 mm

FREQUENTLY ASKED QUESTIONS

Is 8531J81ZQE22 RoHS compliant?

Yes, 8531J81ZQE22 is RoHS compliant.

What is the lead time for 8531J81ZQE22?

The standard lead time for 8531J81ZQE22 is approximately 14 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 220

Ships today, if you order in

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 40

Factory Lead-Time 14 Weeks
