7201SYZQE by littelfuse/c-k

7201SYZQE

Littelfuse/C&K

Miniature Toggle Switch - DP (On-None-On) - 5A@120VAC/2A@250VAC - .420" Actuator - Solder Lug - 1/4-40 Bushing - Epoxy Seal ...

Datasheet
RoHS Compliant
Bulk Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 7103SYCQE with dimensions 12.7 x 6.86 x 30 mm has Panel Mount with Threads mounting with SPDT Pole throw configuration ,On-On switching configuration and Round Lever actuator. The 7103SYCQE has contact rating of 5A@28VDC. This unsealed switch has Thru-hole termination style with Straight body orientation.Used by designers throughout the medical equipment and telecommunications industry to give product designs the long-lasting, high performance switch they need to succeed. The 7000 series are epoxy terminal-seal compatible with bottom wash cleaning and are engineered to be both multi-pole and multi-position, ensuring a perfect fit, no matter the design specifications.

Search Keywords: 7201SYZQE

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Littelfuse/C&K
Part No:
7201SYZQE
RoHS:
Yes
HTS:
8536509040
COO:
VN
ECCN:
EAR99
Supplier Standard Pack  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
Bulk
Pole Throw Configuration:
2P2T (DPDT)
Switch Configuration:
On None On
Contact Rating @ Voltage:
5@120VAC 28VDC A
Actuator Style:
Round Lever
Mounting:
Panel Mount with Threads
Thread Size:
1/4-40
Body Orientation:
Straight
Terminal Type:
Solder
Dimension:
12.7mm x 11.43mm x 32.39 mm
Operating Temperature:
-30 to 85 °C
  Different packaging options available.  See Alternatives

IN STOCK: 980

Can Ship immediately

Minimum Order: 5

Factory Lead-Time 8 Weeks

Qty
Unit Price
5
$11.45
25
$9.23
50
$8.61
100
$8.40
300
$8.14
500
$8.01
1,000 +
$7.97
Suppliers Standard Package
Log in for special pricing
Please Note: Tariffs may apply for U.S. shipments
