7201SYCBE by littelfuse/c-k
Image is representational - see mfr. specs

7201SYCBE

Littelfuse/C&K

Miniature Toggle Switch - DP (On-None-On) - 0.4VA@20V - .420" Actuator - PCB Pin - 1/4-40 Bushing - Epoxy Seal ...

Datasheet
RoHS Compliant
BULK Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 7201SYCBE is a miniature DPDT toggle switch from the C&K 7000 Series designed for compact switching applications requiring dual independent circuits. It features a contact rating of 5 amps at 120 V AC or 28 V DC, and 2 amps at 250 V AC, with contact resistance below 10 mO typical at 2–4 V DC and 100 mA. The switch provides 1000 Vrms minimum dielectric strength at sea level and 10? O minimum insulation resistance, with an electrical life of 40,000 make-and-break cycles at full load. Operating temperature range is -30 °C to +85 °C, and the switch features an epoxy seal with solder lug termination (Z option). This configuration is ideal for control panels, instrumentation, and industrial equipment where reliable dual-circuit switching in a compact form factor is required.

Search Keywords: 7201SYCBE

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Littelfuse/C&K
Part No:
7201SYCBE
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
853650
COO:
VN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
BULK
Pole Throw Configuration:
2P2T (DPDT)
Switch Configuration:
On None On
Contact Rating @ Voltage:
0.4@20VAC 20VDC A
Actuator Style:
Round Lever
Mounting:
PC Mount with Threads
Thread Size:
1/4-40
Body Orientation:
Straight
Terminal Type:
PC Pins
Dimension:
12.7 x 11.43 x 30 mm
Operating Temperature:
-30 to 85 °C

IN STOCK: 31

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
5
$14.18
25
$12.75
50
$12.07
100
$10.96
300
$10.75
500
$10.41
1,000 +
$10.38
