7201P3YZQE by littelfuse/c-k
Image is representational - see mfr. specs

7201P3YZQE

Littelfuse/C&K

Miniature Toggle Switch - DP (On-None-On) - 5A@120VAC/2A@250VAC - .450" Flatted Anti-rotation Actuator - Solder Lug - 1/4-40 Bushing - Epoxy Seal ...

Datasheet
RoHS Compliant
BULK Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The C&K COMPONENTS part 7201P3YZQE is a versatile Miniature Toggle Switch with Double Pole (On-None-On) functionality, rated at 5A@120VAC and 2A@250VAC. Featuring a .450" Flatted Anti-rotation Actuator, Solder Lug terminals, and a 1/4-40 Bushing, this durable switch is designed for high performance in various applications. Additionally, the switch is equipped with an Epoxy Seal for added protection, ensuring reliability in challenging environments.

Search Keywords: 7201P3YZQE

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Littelfuse/C&K
Part No:
7201P3YZQE
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
853650
COO:
VN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
BULK
Pole Throw Configuration:
2P2T (DPDT)
Switch Configuration:
On None On
Contact Rating @ Voltage:
5@120VAC 28VDC A
Actuator Style:
Flat Lever
Mounting:
Panel Mount with Threads
Thread Size:
1/4-40
Body Orientation:
Straight
Terminal Type:
Solder
Dimension:
12.7 x 11.43 x 33.15 mm
Operating Temperature:
-30 to 85 °C

IN STOCK: 298

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 8 Weeks

Qty
Unit Price
5
$12.20
25
$11.49
50
$11.38
100
$10.08
300
$10.03
500
$9.87
1,000 +
$9.82
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
