7101SD9CQE by littelfuse/c-k
Image is representational - see mfr. specs

7101SD9CQE

Littelfuse/C&K

Miniature Toggle Switch - SP (On-None-On) - 5A@120VAC/2A@250VAC - .420" Actuator - PCB Pin - 1/4-40 Bushing - Epoxy Seal ...

Datasheet
RoHS Compliant
BULK Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 7101SD9CQE is a single-pole, on-none-on miniature toggle switch from the C&K 7000 Series, featuring a single-pole double-throw (SPDT) configuration with three positions. The switch is equipped with copper alloy terminals with gold plate over nickel plate (B contact material) and an epoxy terminal seal for environmental protection. It operates over a temperature range of -30°C to 85°C with a contact resistance below 10 mO typical at 2-4 V DC with 100 mA, and provides an insulation resistance of 10? O minimum with a dielectric strength of 1000 Vrms minimum at sea level. The switch supports 40,000 electrical life cycles at full load and is RoHS compliant. Common applications include industrial control panels, instrumentation, and consumer electronics where reliable switching and compact form factor are required.

Search Keywords: 7101SD9CQE

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Littelfuse/C&K
Part No:
7101SD9CQE
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
853650
COO:
VN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
BULK
Pole Throw Configuration:
1P2T (SPDT)
Switch Configuration:
On None On
Contact Rating @ Voltage:
5@120VAC 28VDC A
Actuator Style:
Round Lever
Mounting:
PC Mount
Thread Size:
N/R
Body Orientation:
Straight
Terminal Type:
PC Pins
Dimension:
12.7 x 6.86 x 30 mm
Operating Temperature:
-30 to 85 °C

IN STOCK: 281

Can Ship immediately

Minimum Order Quantity: 15

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
5
$9.15
25
$7.87
50
$7.46
100
$6.81
300
$6.58
500
$6.35
1,000
$6.09
2,500 +
$6.06
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
