B17-254-A-1 by johnson electric
Image is representational - see manufacturer specifications
Johnson Electric Authorized Distributor

B17-254-A-1

The B17-254-A-1 is a miniature, high-speed, linear open-frame pull solenoid. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The B17-254-A-1 is a linear open-frame solenoid from the Ledex® Box Frame Size B17 series, designed for pull-type actuation. It features a nominal coil resistance of 88.95 ohms at 20°C and is constructed with 2208 nominal turns. This solenoid is rated for operation at various duty cycles, with nominal voltages of 12 VDC for continuous duty (100%), 17 VDC for 50%, 24 VDC for 25%, and 38 VDC for a 10% duty cycle. General characteristics for the series include a holding force of 14.04 oz (3.9 N), Class 'B' coil insulation rated to 130°C, and a dielectric strength of 500 VRMS. Its miniature size and high-speed operation make it suitable for applications requiring compact and responsive linear motion.

Search Keywords: B17254A1

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Johnson Electric
Part No:
B17-254-A-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8505902999
COO:
MY
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
500
Maximum Stroke Length:
N/A
Operating Temperature:
N/A
Type:
Box Frame
Coil Voltage:
12 VDC
Coil Current:
N/A
Operation:
Pull

FREQUENTLY ASKED QUESTIONS

Is B17-254-A-1 RoHS compliant?

Yes, B17-254-A-1 is RoHS compliant.

What is the lead time for B17-254-A-1?

The standard lead time for B17-254-A-1 is approximately 13 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 0

On Order: 360   can ship 11/6/26

MOQ for out of Stock Qty: 125

Factory Lead-Time 13 Weeks

Price (USD)

Qty
Unit Price
1
$52.00
25
$30.87
50
$27.85
125
$27.17
250
$25.96
375
$25.89
500 +
$25.83
