Image is representational - see manufacturer specifications
Johnson / Cinch Connectivity Solutions Authorized Distributor

142-1000-002

The 142-1000-002 is a 50 Ohm hermetically sealed feedthru connector designed for high-frequency applications from DC to 26.5 GHz. ...

View Datasheet Ask the Datasheet
RoHS Compliant
BAG Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The 142-1000-002 is a 50 Ohm hermetically sealed feedthru connector designed for high-frequency signal transmission. It features a nominal impedance of 50 Ohms and operates over a frequency range from DC to 26.5 GHz. The construction includes a Kovar outer ring and pin, both with a minimum of .00005 inches of gold plating over nickel, and a Corning 7070 glass insulator for a robust hermetic seal. This feedthru has a working voltage of 250 VRMS, a dielectric withstanding voltage of 500 VRMS, and a minimum insulation resistance of 5000 Megohms. With an operating temperature range of -55°C to +165°C and a hermeticity rating of 1x10⁻⁸ at one atmosphere, it is ideal for demanding applications requiring a reliable, sealed connection in harsh environments.

Search Keywords: 1421000002

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Johnson / Cinch Connectivity Solutions
Part No:
142-1000-002
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8538908140
COO:
US
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
25
Package Type:
BAG
Type:
Hermetic Seal Feed-Thru
Operating Temperature:
-55 to 165 °C
Dimension:
7.99 x 2.5 mm

FREQUENTLY ASKED QUESTIONS

Is 142-1000-002 RoHS compliant?

Yes, 142-1000-002 is RoHS compliant.

What is the lead time for 142-1000-002?

The standard lead time for 142-1000-002 is approximately 9 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 1,310

Can Ship immediately

Minimum Order Quantity: 25

Multiple: 25

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
25
$5.82
50
$5.49
100
$5.17
250
$5.16
500
$4.61
1,000
$4.40
2,500
$4.12
5,000 +
$4.11
