142-0711-841 by johnson / cinch connectivity solutions
Image is representational - see mfr. specs

142-0711-841

Johnson / Cinch Connectivity Solutions

The 142-0711-841 is an SMA end launch jack assembly designed for board-edge mounting in RF applications. ...

Datasheet
RoHS Compliant
Bag Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 142-0711-841 is an SMA end launch jack assembly used for terminating RF signals at the edge of a printed circuit board. This connector is engineered with a characteristic impedance of 50 Ohms and operates over a broad frequency range from DC to 18 GHz. It provides reliable electrical performance with a dielectric withstanding voltage of 1000 VRMS minimum and an insulation resistance of 5000 megohms minimum. Designed for durability with a rating of 500 mating cycles and an operating temperature range of -65°C to 165°C, it is well-suited for high-frequency test equipment, telecommunications hardware, and aerospace systems.

Search Keywords: 1420711841

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Johnson / Cinch Connectivity Solutions
Part No:
142-0711-841
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
Bag
Type:
SMA
Impedance:
50 Ohm
Operating Frequency:
0 to 18 Hz to GHz
Gender:
RCP
Mounting:
Edge Mount
Body Orientation:
Straight
Terminate To:
PCB
Termination Method:
Solder
Operating Temperature:
-65 to 165 °C
Dimension:
6.35 x 13.33 x 6.35 mm

IN STOCK: 16

Can Ship immediately

Buy all 16 in-stock or the regular minimum order quantity of 25

On Order: 1,000   can ship 7/17/26

Stock lot only: 16

Minimum Order Quantity: 25

Multiple: 25

Factory Lead-Time 16 Weeks

Qty
Unit Price
1
$8.338
25
$7.580
50
$6.820
100
$6.490
250
$5.760
500
$5.490
1,000
$5.230
2,500
$5.200
5,000 +
$5.180
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides
