142-0701-881 by johnson / cinch connectivity solutions
Image is representational - see mfr. specs

142-0701-881

Johnson / Cinch Connectivity Solutions

The 142-0701-881 is a 50 Ohm SMA end launch jack assembly designed for RF applications up to 18 GHz. ...

Datasheet
RoHS Compliant
Bag Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 142-0701-881 is a 50 Ohm SMA end launch jack assembly. It is engineered to operate over a frequency range from DC to 18 GHz. Key electrical characteristics include a working voltage of 335 VRMS maximum, a dielectric withstanding voltage of 1000 VRMS minimum, and an insulation resistance of 5000 megohms minimum. Mechanically, it features a mating torque of 7-10 inch-pounds and is rated for a durability of at least 500 cycles. This connector is built to withstand harsh conditions, meeting MIL-STD-202 for thermal shock, corrosion, shock, and vibration, with an operating temperature range of -65°C to 165°C.

Search Keywords: 1420701881

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Johnson / Cinch Connectivity Solutions
Part No:
142-0701-881
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
Bag
Type:
SMA
Impedance:
50 Ohm
Operating Frequency:
0 to 18 Hz to GHz
Gender:
RCP
Mounting:
Edge Mount
Body Orientation:
Straight
Terminate To:
PCB
Termination Method:
Solder
Operating Temperature:
-65 to 165 °C
Dimension:
9.52 x 14.27 x 7.92 mm

IN STOCK: 476

Ships today, if you order in

Minimum Order Quantity: 25

Multiple: 25

Factory Lead-Time 9 Weeks

Qty
Unit Price
25
$7.63
50
$7.20
100
$6.80
250
$6.35
500
$6.04
1,000
$5.75
2,500 +
$5.73
