MDM-31SBSP-A174 by itt cannon
Image is representational - see mfr. specs

MDM-31SBSP-A174

ITT CANNON

Conn Micro D-Subminiature SKT 31 POS 1.27mm Solder ST Thru-Hole 31 Terminal 1 Port ...

Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The ITT Cannon part 096519-0182 is a high-quality and reliable electrical connector designed for a variety of industrial applications. With its rugged construction and superior performance, this connector ensures a secure and efficient electrical connection in even the harshest environments. It features a compact design for easy installation and is manufactured to meet the highest industry standards for durability and performance. The ITT Cannon part 096519-0182 is a trusted choice for professionals in various industries, including aerospace, military, automotive, and telecommunications.

Search Keywords: MDM31SBSPA174

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ITT CANNON
Part No:
MDM-31SBSP-A174
Alias/AKA:
096519-0182
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Insulator Resistance:
5000 megohms min.
Physical Shock:
50 Gs, 3 axes, 6 milisecond duration sawtooth pulse
Current Rating:
3 A max.
Shell Material:
Aluminum
Contact Material:
gold plated copper alloy
Contact Resistance:
8 milliohms max.
Termination Type:
Straight PCB Termination
Disclaimer:
Our facility is not currently certified by the DLA and this product is not covered by the QPL/QML.
Dielectric Withstanding Voltage:
600 VAC at sea level 150 VAC at 70,00 altitude
Moisture Resistance:
Insulator resistance > 100 megohms
Vibration:
20Gs, 10-2000 Hz. 12 hours
Saltspray:
48 hours
Shell Finish:
Electroless Nickel
Contact Type:
Crimp
Insulator Material:
contact size 9 to100 = liquid crystalline polymer, contact arrangements 7C2 or 24C4 = Diallyl phthalate
Series:
Micro "D" Metal Shell
Hardware:
Jackpost (standard)
Thermal Shock:
-55°/+125 °
Durability Rating:
500 cycles of mating and unmating, 500 CPH max.
Pcb Hardware:
no PCB mounting hardware
Coupling:
Jackscrew Coupling
Gender:
Socket
Arrangement:
31 Contact

IN STOCK: 0

MOQ for out of Stock Qty: 3

Factory Lead-Time 16 Weeks

Qty
Unit Price
3
$904.63
5
$574.70
8
$379.14
10 +
$371.56
