M83513/01-DC by itt cannon
Image is representational - see manufacturer specifications
ITT CANNON Authorized Distributor

M83513/01-DC

Conn D-Subminiature PIN 25 POS 1.27mm Solder Pot ST Panel Mount 25 Terminal 1 Port ...

View Datasheet Ask the Datasheet
RoHS Non-Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

M83513/01-DC is a microminiature rectangular connector from the MDM (Micro-D Metal Shell) series, designed for high-reliability applications requiring extremely small, lightweight connectors with high-density contact configurations. It features aluminum shells providing EMI/RFI shielding and greater strength, along with a silicone elastomer compression interfacial seal for moisture and humidity protection. The connector offers a dielectric withstanding voltage of 600 VAC at sea level and 150 VAC at 70,000' altitude, insulation resistance of 5,000 megohms minimum, and operates over a thermal shock range of -55°C to +125°C. It withstands physical shock of 50 G's and vibration of 20 G's (10-2,000 Hz), with durability rated for 500 mating cycles. This connector is ideal for aerospace, military, and industrial applications where rugged, moisture-sealed, high-performance microminiature connectors are required.

Search Keywords: M8351301DC

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ITT CANNON
Part No:
M83513/01-DC
Alias/AKA:
154176-0000-MS
Unit of Measure:
Per Each
RoHS:
No
HTS:
8536694030
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Panel Mount
Gender:
Pin
Termination Method:
Solder Pot
Shell Size:
N/A
Number of Contacts:
25
Contact Plating:
Gold
Operating Temperature:
N/A

FREQUENTLY ASKED QUESTIONS

Is M83513/01-DC RoHS compliant?

No, M83513/01-DC is not RoHS compliant.

What is the lead time for M83513/01-DC?

The standard lead time for M83513/01-DC is approximately 18 days. In-stock quantities ship from Master Electronics.

IN STOCK: 20

Ships today, if you order in

On Order: 50   can ship 8/24/26

Factory Lead-Time 18 Weeks

Price (USD)

Qty
Unit Price
1
$72.55
5
$71.83
10
$71.30
20
$70.96
50
$70.78
100 +
$70.60
Log in for special pricing Click for Quote Price Match Request
