KPSE6E16-26P-DZ

Name: KPSE6E16-26P-DZ Itt Cannon MIL Spec
Brand: Itt Cannon
SKU: 50976990
Availability: InStock

The KPSE6E16-26P-DZ is a shielded, circular straight plug connector from the KPSE series, featuring a size 16 shell, 26 pin contacts, and an endbell for a heat shrink boot. ...

View Datasheet

Ask the Datasheet

RoHS Non-Compliant

Certificate of Compliance

DESCRIPTION

The KPSE6E16-26P-DZ is a straight plug connector from the KPSE series, designed for reliable, high-density signal connections in harsh environments. It features a size 16 shell with 26 pin contacts (size 20), a 1/2 turn positive bayonet coupling for quick mating, and crimp contacts with a clip-in retention system for easy assembly. This specific model includes the 'DZ' modification, providing a shielded endbell compatible with heat shrink boots and a grommet seal for environmental protection up to IP67. With its robust design compliant with VG95328 standards, it is suitable for demanding applications such as military vehicles, industrial machinery, and factory automation equipment.

Product Highlights:

Potential Applications:

Search Keywords: KPSE6E1626PDZ

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

ITT CANNON

Part No:

KPSE6E16-26P-DZ

Alias/AKA:

115383-0216

Unit of Measure:

Per Each

RoHS:

HTS:

8536694020

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
