121583-0025 by itt cannon
Image is representational - see mfr. specs

121583-0025

ITT CANNON

The 121583-0025 is an APD series high-power, 2-way plug connector with socket contacts, designed for transportation applications. ...

Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 121583-0025 is an APD series high-power, 2-way plug connector designed for robust performance in transportation systems. It operates at 48 VDC and features a low maximum contact resistance of 2 mΩ, ensuring efficient power transmission. This connector is built for durability with a rating of 50 mating cycles, an IP67 sealing rating for protection against dust and water ingress, and a wide operating temperature range of -40°C to 125°C. The housing is made from PBT GF, and it can withstand a static load of 350 N and a voltage proof of 1000 VAC. Its resilience to vibration, common industrial fluids, and salt spray makes it highly suitable for demanding vehicle and industrial environments.

Search Keywords: 1215830025

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ITT CANNON
Part No:
121583-0025
Alias/AKA:
APD-1BSH8-2
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8538906000
COO:
PL
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Contact Plating:
Silver
Contacts Classification:
N/A
Contact Material:
Copper Alloy
Contact Resistance:
2 mΩ max
Coding (Mechanical Keying And Visual Color Coding):
Code 1 - black (RAL 9005)
Body Orientation:
Straight
Contact Gender:
SKT
Connector Type:
Plug

IN STOCK: 508

Ships today, if you order in

On Order: 340   can ship 5/25/26

Minimum Order Quantity: 5

Factory Lead-Time 7 Weeks

Qty
Unit Price
5
$10.03
25
$8.19
50
$7.72
100
$7.28
300
$6.74
500
$6.50
1,000 +
$6.19
Suppliers Standard Package
