RR3B-ULCDC24V by idec corporation
Image is representational - see mfr. specs

RR3B-ULCDC24V

IDEC Corporation

Power Relay 24VDC 10A 3PDT(36x36x47.5)mm Socket ...

Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The RR3B-ULCDC24V is a 3-pole general-purpose power relay manufactured by IDEC with a 24 VDC coil and blade-style termination, featuring an indicator light and check button for test operation. The relay operates at a rated coil voltage of 24 VDC with a coil current of 60 mA and coil resistance of 400 O at 20 °C, with an operating time of 25 ms maximum and release time of 25 ms maximum. Contact ratings include 10 A at 30 VDC resistive load and 7.5 A at 30 VDC inductive load, with silver contact material and a maximum contact resistance of 30 mO. The relay is rated for a minimum operating voltage of 80% of rated voltage and a maximum continuous applied voltage of 110% of rated voltage, with a minimum applicable load of 24 V DC/10 mA. This relay is commonly used in industrial control systems, automation equipment, and power distribution applications where reliable switching of moderate DC loads is required.

Search Keywords: RR3BULCDC24V

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
IDEC Corporation
Part No:
RR3B-ULCDC24V
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
TH
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
3PDT
Mounting:
Socket
Termination Style:
Solder
Push to Test Button:
Yes
Led Indicator:
Yes
Operating Temperature:
-30 to 70 °C
Coil Resistance:
400 Ohm

IN STOCK: 89

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
5
$25.32
10
$24.05
25
$22.41
50
$21.06
100
$19.82
250
$19.77
500 +
$19.73
