HW1B-M1F22-B by idec corporation
Image is representational - see mfr. specs

HW1B-M1F22-B

IDEC Corporation

A 22mm momentary, non-illuminated round flush pushbutton switch with a black plastic bezel and a 2NO-2NC contact configuration. ...

Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The HW1B-M1F22-B is a non-illuminated, momentary action pushbutton switch from the HW series, designed for a 22mm panel cutout. It features a black, round flush operator with a plastic bezel and provides a 2NO-2NC contact configuration. The switch incorporates finger-safe (IP20) contact blocks with slow make, double-break, self-cleaning silver contacts, a rated insulation voltage of 600V, and a thermal current of 10A. This robust switch is easy to assemble and suitable for a wide range of industrial control applications requiring reliable momentary switching, benefiting from worldwide approvals and a high mechanical life.

Search Keywords: HW1BM1F22B

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
IDEC Corporation
Part No:
HW1B-M1F22-B
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509035
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Mounting:
Panel Mount
Pole Throw Configuration:
4PST
Bushing Type:
Threaded
Switch Configuration:
N.O./N.C.
Contact Rating @ Voltage:
745.7 A
Actuator Style:
Flush Round Button
Illumination:
N/R
Terminal Type:
Screw
Body Orientation:
Straight

IN STOCK: 0

Factory Lead-Time 9 Weeks

Qty
Unit Price
1
$32.26
5
$30.18
10
$28.78
25
$27.93
50
$26.73
100
$25.63
250 +
$24.95
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
