HS9Z-A52 by idec corporation
Image is representational - see mfr. specs

HS9Z-A52

IDEC Corporation

Switch Access Actuator Door Interlock Switch ...

Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The HS9Z-A52 is a compact actuator accessory for IDEC door interlock switches, specifically engineered for hinged door applications. It features adjustable mounting with M4 hex socket head cap screws and is compatible with HS5E/HS5B series interlock switches. The actuator supports minimum door hinge radii of 170 mm (when door hinge is on the extension line of the interlock switch surface) and 230 mm (when door hinge is on the extension line of the actuator mounting surface), with additional configurations for horizontal and vertical swing applications. Installation requires a recommended tightening torque of 2.0±0.2 N·m (approximately 20±2 kgf·cm) using 2 pcs of M4 hex socket head cap screws. This actuator is commonly used in industrial safety applications where mechanical door locking is required during machine operation, providing reliable actuation for safety-critical door interlock systems.

Search Keywords: HS9ZA52

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
IDEC Corporation
Part No:
HS9Z-A52
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504404000
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Type:
Actuator
Switch Type:
Door Interlock Switch
Color:
N/A

IN STOCK: 114

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
5
$9.12
25
$8.54
50
$8.30
100
$8.05
250
$7.72
500
$7.47
1,000 +
$7.22
