MINIBEND-L-6 by huber+suhner
Image is representational - see manufacturer specifications
HUBER+SUHNER Authorized Distributor

MINIBEND-L-6

The 80337298 is a 6-inch, 50 Ohm low-loss flexible cable assembly terminated with two straight SMA male plugs, designed for applications up to 26.5 GHz. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The 80337298, known as the MINIBEND L-6, is a 152.4 mm (6 inch) flexible, low-loss cable assembly. It operates with a 50 Ω impedance up to a maximum frequency of 26.5 GHz, exhibiting a maximum VSWR of 1.4 and an insertion loss of 0.85 dB at its highest frequency. This assembly features a low loss PTFE dielectric, operates over a temperature range of -55 °C to 125 °C, and is terminated with straight SMA male plugs on both ends. As a direct replacement for 086 size semi-rigid cables, it is ideal for high-frequency applications requiring flexible interconnects within tight spaces.

Search Keywords: MINIBENDL6

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
HUBER+SUHNER
Part No:
MINIBEND-L-6
Alias/AKA:
80337298
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8544200000
COO:
CR
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1

FREQUENTLY ASKED QUESTIONS

Is MINIBEND-L-6 RoHS compliant?

Yes, MINIBEND-L-6 is RoHS compliant.

What is the lead time for MINIBEND-L-6?

The standard lead time for MINIBEND-L-6 is approximately 16 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 10

Ships today, if you order in

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
1
$84.05
5
$77.78
10
$68.07
20
$65.16
50
$49.08
100 +
$43.43
