MINIBEND-L-12 by huber+suhner
Image is representational - see mfr. specs

MINIBEND-L-12

HUBER+SUHNER

The 80337202 is a low-loss, 50 Ohm flexible cable assembly terminated with straight male SMA connectors, designed for applications up to 26.5 GHz. ...

Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 80337202, part of the MINIBEND L-12 series, is a 12-inch (304.8 mm) low-loss coaxial cable assembly. It operates with a characteristic impedance of 50 Ω and supports frequencies up to 26.5 GHz, exhibiting a maximum VSWR of 1.4 and an insertion loss of 1.39 dB at its maximum frequency. The cable features a low loss PTFE dielectric, a diameter of 2.64 mm, and is terminated on both ends with straight male SMA plugs. Designed as a flexible, direct replacement for 086 size semi-rigid cables, it is suitable for various RF applications requiring reliable performance in a wide temperature range from -55 °C to 125 °C.

Search Keywords: MINIBENDL12

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
HUBER+SUHNER
Part No:
MINIBEND-L-12
Alias/AKA:
80337202
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8544200000
COO:
CR
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
5

IN STOCK: 10

Can Ship immediately

Factory Lead-Time 8 Weeks

Qty
Unit Price
1
$91.08
5
$84.28
10
$73.76
20
$70.60
50
$53.18
100 +
$47.07
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
