PCS-E68FS+ by htk honda
Image is representational - see manufacturer specifications
HTK HONDA Authorized Distributor

PCS-E68FS+

Conn SCSI F 68 POS 1.27mm Solder ST Cable Mount 68 Terminal 1 Port ...

View Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The PCS-E68FS+ is a 68-contact soldering type female connector for cable applications, part of the PCS series 1.27 mm pitch connector family designed for high-density board-to-cable interfaces. This connector features a compact soldering termination suitable for AWG #20 maximum cable sizes and includes an insulator, shell, spacer, and contact components for robust mechanical and electrical performance. The connector dimensions are 52.1 mm (A), 41.91 mm (B), and 45.88 mm (C), with 1.27 mm contact pitch spacing and 2.54 mm row spacing. It is designed to mate with PCS-E series through-hole type male connectors for PCB and PCS-E series IDC type male connectors for panel applications. This connector is commonly used in office automation equipment and other downsized electronic equipment requiring reliable, high-density interconnections with soldering-based termination.

Search Keywords: PCSE68FS

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
HTK HONDA
Part No:
PCS-E68FS+
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
JP
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
400
Type:
SCSI
Body Orientation:
Straight
Mounting:
Cable Mount
Gender:
F
Termination Method:
Solder
Pitch:
1.27 mm
Number of Contacts:
68
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
1 A

FREQUENTLY ASKED QUESTIONS

Is PCS-E68FS+ RoHS compliant?

Yes, PCS-E68FS+ is RoHS compliant.

What is the lead time for PCS-E68FS+?

The standard lead time for PCS-E68FS+ is approximately 26 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 77

Can Ship immediately

MOQ for In Stock Qty: 25

MOQ for out of Stock Qty: 25

Factory Lead-Time 26 Weeks

Price (USD)

Qty
Unit Price
1
$38.489
25
$34.990
50
$34.900
100
$34.820
200
$18.430
300
$12.970
400 +
$12.710
