V15H16-CZ100A02-K by honeywell
Image is representational - see mfr. specs

V15H16-CZ100A02-K

Honeywell

MICRO SWITCH™ Basic Switches: V-Basic Standard V15 Series, Temperature Grade 150° C [302° F], 16 A 125/250 Vac, 6,3 mm x 0,8 mm Quick Connect Terminals, Single Pole Double Throw (SPDT), Operating Force 100 gf, Standard Straight Lever Positioned Far From Pin Plunger, USA Mounting Holes ...

Datasheet
RoHS Compliant
BOX Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

MICRO SWITCH™ Basic Switches: V-Basic Standard V15 Series, Temperature Grade 150° C [302° F], 16 A 125/250 Vac, 6,3 mm x 0,8 mm Quick Connect Terminals, Single Pole Double Throw (SPDT), Operating Force 100 gf, Standard Straight Lever Positioned Far From Pin Plunger, USA Mounting Holes

Search Keywords: V15H16CZ100A02K

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
V15H16-CZ100A02-K
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
85365011
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
BOX
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Straight Lever
Contact Rating @ Voltage:
372.85 A
Maximum Movement Differential:
1.2 mm
Operating Force:
0.59 N
Termination Style:
Quick Connect
Dimension:
50.3 x 10.3 x 25 mm
Body Orientation:
Straight
IP Rating:
N/A

IN STOCK: 1,510

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 7 Weeks

Qty
Unit Price
5
$3.53
50
$3.16
100
$3.09
250
$3.04
500
$2.96
1,000
$2.92
3,000
$2.16
5,000 +
$2.13
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides
