SS461A by honeywell

SS461A

Honeywell

Honeywell Hall-effect Digital Position Sensor ICs: SS400 Series, Temperature compensated latching Hall-effect sensor IC, High sensitivity, Low Gauss, Flat TO-92 package, Straight leads, 14,99 mm [0.59 in] long, Available in bulk pack of 1000 units per bag ...

Datasheet
RoHS Compliant
BAG Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

Honeywell SS461A Hall Effect Sensor features Quad-Hall IC design that helps minimize mechanical stress effects. SS461A has temperature-compensated magnetics, which allow stable operations over a wide range of temperatures from -40 °C to 150 °C.

This Honeywell sensor is used in diverse industrial, transportation and medical applications like speed and RPM sensing, robotics control, motor and fan control, tachometer, electronic window lift, convertible roof position, and medical equipment, by using electric motors. Hall effect sensors are triggered by a magnetic field and operate as analog transducers to return the required voltage directly. These sensors vary their output voltage in response to a magnetic field.

Product Highlights:

    li>Quad-Hall IC design minimizes mechanical stress effects
  • Temperature-compensated magnetics helps provide stable operation over a wide temperature range of -40 °C to 150 °C
  • Broad supply voltage capability from 3.8 Vdc to 30 Vdc provides for diverse applications
  • Digital, open collector sinking output allows easy interfacing with a variety of common electronic circuits
  • Miniature standard 3-lead plastic package with tape option for automated component placement, potentially reducing installation costs

Search Keywords: SS461A

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
SS461A
RoHS:
Yes
HTS:
8542390001
COO:
CN
ECCN:
EAR99
Supplier Standard Pack  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
BAG
Magnetic Type:
Bipolar Latch
Maximum Output Current:
20 mA
Mounting:
PCB Through Hole
Minimum Magnetic Sensor Release Point:
-85 Gs
Maximum Magnetic Sensor Operating Point:
85 Gs
Output Type:
Sink
Output Driver:
NPN
Product Type:
Digital
Dimension:
4.06 x 1.57 x 3 mm
Typical Operating Supply Voltage:
3.8 to 30 V
Termination Type:
PC Pins
Operating Temperature:
-40 to 150 °C

IN STOCK: 95,144

Can Ship immediately

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 1250

Factory Lead-Time 7 Weeks

Qty
Unit Price
5
$6.66
250
$4.44
500
$4.42
1,250
$4.39
2,500
$4.37
3,750
$4.35
5,000 +
$4.09
Log in for special pricing
