3LS1

MICRO SWITCH™ General Purpose Limit Switches: LS Series, Epoxy-Coated Zinc Housing, Non Plug-in Body Style, Side Roller Plunger, Ø 16,7 mm x 4,8 mm [0.66 in x 0.19 in] SST Roller, Roller Plunger May Be Locked in Any Position Through 360°, 1NC 1NO Single Pole Double Throw (SPDT) Snap Action, Double Break, 10 A 120, 240, or 480 Vac, 0.5 in - 14 NPT Conduit, Operating Temperature: -29 °C to 71 °C [-20 °F to 160 °F], NEMA 1, 3, 4, 6 and 13 ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The HONEYWELL part 3LS1 is a MICRO SWITCH„¢ General Purpose Limit Switch that features an epoxy-coated zinc housing and a non-plug-in body style. It has a side roller plunger with a diameter of 16.7 mm and a thickness of 4.8 mm. The switch is equipped with a stainless steel roller with a diameter of 0.66 in and a thickness of 0.19 in.The unique design of this limit switch allows the roller plunger to be locked in any position through 360°, providing versatility in various applications. It has a 1NC 1NO single pole double throw (SPDT) snap action, double break configuration.With a current rating of 10 A and voltage options of 120, 240, or 480 Vac, this switch is capable of handling a wide range of electrical loads. It features a 0.5 in - 14 NPT conduit for easy installation and is designed to operate in temperatures ranging from -29 °C to 71 °C (-20 °F to 160 °F).The 3LS1 limit switch has a NEMA 1, 3, 4, 6, and 13 rating, making it suitable for use in various indoor and outdoor environments. It is a reliable and durable solution for applications that require accurate and dependable position sensing.

Product Highlights:

  • Mode of operation is field adjustable
  • NEMA 1, 3, 4, 6, and 13
  • Wide choice of heads and actuators
  • Variety of operating characteristics
  • Captive screws
  • UL and CSA approved parts available

Potential Applications:

  • Machine tools
  • Conveyors
  • Material handling
  • Metal fabrication equipment
  • Lift trucks

Search Keywords: 3LS1

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
3LS1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
85365009
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Type:
Enclosed
Actuator Style:
Side Roller Plunger
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Operating Force:
40.03 N
Dimension:
39.88 x 70.33 x 93.98 mm
Maximum Current Rating:
0.8@115VDC A
Terminal Type:
Conduit
NEMA Standard as Enclosure Rating:
1, 3, 4, 6, 13
Body Orientation:
Right Angle

FREQUENTLY ASKED QUESTIONS

Is 3LS1 RoHS compliant?

Yes, 3LS1 is RoHS compliant.

What is the lead time for 3LS1?

The standard lead time for 3LS1 is approximately 40 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 9

Can Ship immediately

On Order: 25   can ship 2/1/27

Factory Lead-Time 40 Weeks

Price (USD)

Qty
Unit Price
1
$423.84
3
$419.71
5 +
$418.66
