1XE401-T by honeywell
Image is representational - see mfr. specs

1XE401-T

Honeywell

MICRO SWITCH™ Subminiature Environmentally Sealed Basic Switches: XE Series, Single Pole Double Throw (SPDT), 1 A at 28 Vdc, Gold-Plated Bifurcated Contacts, Stainless Steel Enclosure, Solder-Plated Terminals, -53 °C to 105 °C [-65 °F to 221 °F] Temperature Range ...

Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The HONEYWELL part 1XE401-T is a high-quality MICRO SWITCH™ subminiature environmentally sealed basic switch from the XE Series. This switch features a single pole double throw (SPDT) configuration, capable of handling 1 A at 28 Vdc. The gold-plated bifurcated contacts ensure excellent electrical conductivity and reliability. Encased in a durable stainless steel enclosure, this switch offers protection against harsh environments. The solder-plated terminals provide easy and secure connection. With a wide temperature range of -53 °C to 105 °C [-65 °F to 221 °F], this switch can withstand extreme temperatures, making it an ideal choice for a variety of applications.

Product Highlights:

  • Very small package size
  • Power load switching capability to 7 A
  • Temperature tolerance to 105 C [221 F]
  • High temperature construction for use to 149 C [300 F]
  • Watertight seal per MIL-S-8805, enclosure design symbol 3
  • Choice of actuation

Potential Applications:

  • Aircraft
  • Ordinance
  • Moist or dusty industrial environments

Search Keywords: 1XE401T

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
1XE401-T
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
85365080
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Steel/Pin Plunger
Contact Rating @ Voltage:
1@28VDC A
Maximum Movement Differential:
0.13 mm
Operating Force:
4.73 N
Termination Style:
Solder
Dimension:
15.65 x 8.03 x 18.92 mm
Body Orientation:
Straight
IP Rating:
N/A

IN STOCK: 238

Can Ship immediately

Factory Lead-Time 28 Weeks

Qty
Unit Price
1
$193.43
5
$190.80
10
$189.55
20
$187.14
50
$158.08
100 +
$137.81
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides
