680-1028-2-28 by hirose electric americas
Image is representational - see mfr. specs

680-1028-2-28

Hirose Electric Americas

7.92mm Contact Pitch High-Current Connectors for Internal Power Supplies (UL, C-UL and TÜV Listed) ...

Datasheet
RoHS Compliant
Bag Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The DF22R-3S-7.92C(28) is a 3-position high-current connector from the DF22 Series designed for internal power supply applications. It features a 7.92 mm contact pitch with a rated current of 25 A (using 10 AWG conductor) and is rated for 1000 V AC/DC. The connector incorporates a positive locking mechanism with a completely enclosed locking system to prevent accidental disconnection, a right-side guide key (color black), and built-in posts for correct board placement and orientation. Each contact is electrically isolated from adjacent contacts by housing walls to prevent short circuits, and the connector supports resin sealing up to 10 mm. It operates across a temperature range of -55 °C to +85 °C and is UL, C-UL, and TÜV certified, making it suitable for high-reliability power distribution, battery isolation, and internal wiring in industrial and electronic equipment.

Search Keywords: 6801028228

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Hirose Electric Americas
Part No:
680-1028-2-28
Alias/AKA:
DF22R-3S-7.92C(28)
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8538906000
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
Bag

IN STOCK: 1,800

Can Ship immediately

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 10 Weeks

Price (USD)

Qty
Unit Price
100
$0.4230
500
$0.3489
1,000
$0.3281
2,500
$0.3053
5,000
$0.2907
7,500
$0.2900
10,000
$0.2800
15,000 +
$0.2793
Suppliers Standard Package
