M7567-05 by harwin

Image is representational - see manufacturer specifications

Harwin Authorized Distributor

M7567-05

The M7567-05 is a 2.54mm pitch jumper socket designed to interconnect two adjacent 0.64mm square or round section pins. ...

Ask the Datasheet

RoHS Compliant

DESCRIPTION

The M7567-05 is a jumper socket from the M75XX range, intended to interconnect two adjacent pins on 2.54mm pitch centers. It features a maximum current rating of 1A and a proof voltage of 500V AC. This component ensures a reliable connection with a minimum insertion force of 2.0N and a maximum withdrawal force of 7.4N. Designed for a wide operating temperature range of -55°C to +105°C, the M7567-05 is suitable for creating temporary electrical bridges on printed circuit boards for configuration, testing, or mode selection.

Product Highlights:

Potential Applications:

Search Keywords: M756705

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Harwin

Part No:

M7567-05

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536698000

COO:

GB

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

1000

FREQUENTLY ASKED QUESTIONS

Is M7567-05 RoHS compliant?

Yes, M7567-05 is RoHS compliant.

What is the lead time for M7567-05?

The standard lead time for M7567-05 is approximately 7 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 14,000

Can Ship immediately

BONDED Quantity: 0

Manufacturer Stock: 0

Stock lot only:

Minimum Order Quantity: 1000

MOQ for out of Stock Qty:

Multiple: 1000

Factory Lead-Time 7 Weeks

This product is no longer being manufactured but there may be alternatives. We can help you, Contact Us.
