117F4 by hammond manufacturing
Image is representational - see mfr. specs

117F4

Hammond Manufacturing

The 117F4 is a 4W line matching audio transformer designed to couple a 4-ohm speaker to a 70V line. ...

Datasheet
RoHS Compliant
Bag Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 117F4 is a line matching audio transformer intended for sound distribution systems. It is designed to couple a 4-ohm voice coil speaker to a 70V amplifier line output. This transformer has a maximum power rating of 4 watts and offers five primary power taps at 4W, 2W, 1W, 0.5W, and 0.25W to match speaker power requirements. Key performance characteristics include a frequency response of 100 Hz to 9 kHz, insertion loss of less than 2 dB, and distortion under 1.25% at 100 Hz. The unit features a horizontal channel bracket for mounting and solder lug terminals, making it ideal for various public address and background music applications.

Search Keywords: 117F4

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Hammond Manufacturing
Part No:
117F4
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
62398018640
COO:
CA
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Bag

IN STOCK: 25

Can Ship immediately

Manufacturer Stock: 25   can ship 5/4/26

Factory Lead-Time 4 Weeks can ship 5/20/26

Qty
Unit Price
1
$26.03
5
$24.45
10
$23.40
25
$22.75
50
$21.84
100
$21.01
250 +
$20.49
Log in for special pricing Click for Quote Price Match Request
