94HCB16T

Switch DIP SP16T 16 Knob 0.03A 30VDC Gull Wing 10000Cycles 2.54mm SMD Tube ...

View Datasheet Ask the Datasheet
RoHS Compliant
TUBE Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The 94HCB16T is a rotary DIP switch from Grayhill's Series 94H that provides 16-position hexadecimal (0 through F) binary coded output with complementary code capability. It features sealed construction requiring no tape seal, gold-plated contacts, and is available in both surface mount (gullwing) and thru-hole configurations with right angle mounting options. The switch supports multiple actuator styles including flush and extended types (.270", .170", or .090" extensions), with standard or complementary output options indicated by rotor color. With dimensions of 0.500" × 0.380" × 0.225" and terminal specifications of 0.020" ± 0.004"/-0.002" wide by 0.012" ± 0.002" thick, this switch is designed for applications requiring reliable position encoding in industrial control systems, test equipment, and configuration settings where hexadecimal input selection is needed.

Search Keywords: 94HCB16T

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Grayhill
Part No:
94HCB16T
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536507000
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
27
Package Type:
TUBE
Body Orientation:
Straight
Actuator Style:
Knob
Actuator Length:
4.32 mm
Number of Positions:
16
Pole Throw Configuration:
SP16T
Mounting:
Surface Mount
Terminal Type:
Gull Wing
Contact Rating @ Voltage:
0.03@30VDC A
Contact Plating:
Gold/Nickel
Terminal Pitch:
2.54 mm
